Description
The MN034 FBS4 Personalization Expert license allows personalization of second-hand or brand-new FBS4 modules (set to virgin state) with or without available FBS4 data via OBDII and internal CAN-Bus connection. This is a major tool for working with modules from the FBS4 generation Mercedes-Benz vehicles.
Get the job done without the data from the original module!
Fast and user-friendly exchange of modules!
No dealer account needed!
Supported modules:
Transmission Control Units: VGS-FDCT/VGS2-FDCT (7G DCT), VGS4-NAG2 (7G-Tronic), VGSNAG3 (9G-Tronic), VGS-DCT (8G FDCT)
- Personalization of virgin modules via OBDII and internal CAN-Bus connection (using FBS4 data read from the original module)
- Personalization of brand-new and unused modules via OBDII and internal CAN-Bus connection (using FBS4 data read from the orignal module)
For ALL Engine Control Units
- Personalization of virgin or brand-new modules for ALL ECU types, using FBS4 data read from the orignal module, via OBDII and internal CAN-Bus connection! (Standard personalization)
- Personalization of virgin or brand-new MED17 and EDC17 by OBDII when NO PREVIOUSLY SAVED PERSONALIZATION DATA FROM THE ORIGINAL MODULE IS AVAILABLE!
- Personalization of Delphi CRD3xx ECUs without previously saved FBS4 data from the original module!
Hybrid vehicle ECUs (INV20EM01 and derivatives)
- Personalization of virgin or brand-new modules, using FBS4 data read from the orignal module, by OBD and internal CAN-Bus connection (Standard personalization)
- Personalization of Inverter Control Module (INV20EM01) without previously saved FBS4 data from the original module!
Electric vehicle ECUs (EM01, EM02)
- Personalization of virgin or brand-new modules, using FBS4 data read from the orignal module, by OBD and internal CAN-Bus connection (Standard personalization)
DSM (all types of models) installed in vehicles equipped with VGS4-NAG2 (7G-Tronic)
- Personalization of modules, using FBS4 data read from the original module, via OBD and internal CAN-Bus connection – No need to open the module!
Required software:
- MN032 DAS Manager for FBS4 vehicles
Required hardware:
- AVDI – essential in order to use all ABRITES-based products and establish OBD connection
- CB012 Direct CAN-BUS/LIN-BUS Connection Cable Set – required for internal CAN-Bus connection
- ZN151 ABRITES Distribution Box Set – required for personalization of MRD1/MRG1 and MED41 (MED17.7.7) when no previously saved personalization data is available
- ABPROG and ZN086 – required for personalization of DSM when no previously saved personalization data is available
- CB030 Mercedes-Benz MD1/MG1 ECU connection cable for FBS4 Manager and ECU Programming Tool
- CB403 Extended Cable Set for all TCUs which require bench connection – for owners of the ZN051 (older iteration of the Distribution Box Set)
Your Annual Subscription (AMS) must be active in order to purchase and use the MN034 license!
